ACUVIEW · Straight-Through Loupes
AcuView Straight-Through Loupes 25AV-ST
The Professional Loupes
The standard choice for entering precision dentistry. Covers 80% of everyday dental procedures — a sound starting point for your first pair.
Send your configuration — our consultant will provide a one-on-one quote
AcuView Straight-Through Loupes
Choose Your Configuration
As simple as getting glasses
Two frame materials, five frame colors, two magnifications — with interpupillary distance and working distance customized to you alone.
Carbon Fiber · Gunmetal Grey · Color subject to actual product
Frame Color
Carbon Fiber · Gunmetal GreyColors are subject to the actual product. Ask our consultant for real photos before ordering.
Magnification
2.5XWorking Distance
Measured laterCustomizable within 300-580mm for the selected magnification. Not sure of your number? Choose "Measured in consultation" — our consultant will guide you through the measurement one-on-one.
Interpupillary Distance
IPD 54-72mm · Made for one
IPD is not a self-select option: our consultant guides you through the measurement one-on-one, and we build to your measured value — no need to estimate here.
Prescription Lenses
Not neededIncluded
- Frame engraving
- AcuBeam headlight compatible (wired / wireless)
- Custom-made to your parameters
Your Configuration
Gunmetal Grey Carbon Fiber · 2.5X · WD measured in consultation · No prescription
Our consultant will provide a one-on-one quote for your configuration · Custom-made to your parameters · one-on-one quote
Key Features
Clear view, lasting comfort
The essence of straight-through loupes is lowering the barrier to seeing clearly: wide field, deep depth of field, light weight — plus full parameter customization.
High-Quality Optical Glass
A+ grade optical lenses with high light transmission, low chromatic aberration, and disinfection resistance. Clear, stable, high-resolution imaging renders caries and gingival inflammation in fine detail with true-to-life color, supporting accurate diagnosis and treatment decisions.
Ultra-Deep Depth of Field
A 200mm depth of field covers everything from the tooth surface to deep gingival areas, reducing frequent refocusing. Bright, clear views keep even dark corners visible for precise pre-operative assessment.
Comfortable Wearing Experience
Approx. 43g total weight, with lightweight, well-fitting carbon fiber or titanium frames. From routine check-ups to complex surgery, long procedures feel burden-free and focus stays sharp.
Fully Customized Parameters
Interpupillary distance (54-72mm) and working distance are tailored to your body; built-in prescription lenses for myopia, astigmatism, and hyperopia eliminate the need for glasses underneath, keeping your workflow smooth.
Specifications
Full Specs & Magnification Comparison
All parameters in the open — every millimeter of a custom product should be clear before you order.
Full Specifications
| Model | 25AV-ST |
|---|---|
| Weight | Approx. 43g (varies with custom parameters) |
| Frame Material | Titanium alloy / Carbon fiber |
| Frame Colors | Carbon fiber: Gunmetal Grey, Satin Silver, Crimson Red | Titanium alloy: Silver, Champagne Gold |
| Barrel Material | Aluminum alloy |
| Lens Material | A+ grade optical lenses |
| Interpupillary Distance | 54-72mm |
| Prescription Customization | Available |
| Frame Engraving | Available |
Choosing a Magnification
| Mag. | Working Distance | Field of View | Depth of Field | Best For |
|---|---|---|---|---|
| 2.5X | 300-580mm | 150-170mm | 200mm | Everyday exams, prophylaxis, routine restorative — wide field, easy adaptation |
| 3.5X | 400-700mm | 110-130mm | 200mm | Restorative, periodontal, and other fine work — richer detail |
Ergonomic Evidence
Extend the working distance, minimize the bend
The straight-through optical path still directs your gaze downward, but a customized long working distance turns "pressing close to see" into "a slight forward lean". Combined with an upright sitting posture, neck and shoulder strain drops significantly — which is exactly why custom parameters must be measured accurately.
0.0%
Overall MSD prevalence in the past 12 months (n=614)
0.0%
Neck prevalence (highest of 9 body sites)
0.0%
Lower Back prevalence
Source: Zhang et al. 2021, Occupational Health and Emergency Rescue, 39(1): 6-11, DOI: 10.16369/j.oher.issn.1007-1326.2021.01.002
Buying Guide
Read these before you decide
No marketing talk — just optical parameters, posture impact, and who each option fits.
Made for One
Custom-made to your parameters
Every ACUVIEW loupe is built to one clinician's interpupillary distance, working distance, and prescription — never a stock size.
- Custom parameters
- Interpupillary distance 54-72mm; working distance set to your posture and magnification; frame engraving available.
- Prescription lenses
- Built-in correction for myopia, astigmatism, and hyperopia — no need to wear glasses under your loupes.
- One-on-one consultation
- A specialist confirms every parameter with you before production, so the loupes fit the way you actually work.
- 1
Send an inquiry and tell us your specialty, typical procedures, and any equipment you use now.
- 2
Our consultant helps you choose magnification and frame, and guides you through measuring your parameters.
- 3
Your loupes are custom-made to the confirmed parameters — one pair, made for one person.
- 4
After delivery, we follow up with fitting guidance and parameter adjustment support.
FAQ
Frequently Asked Questions
Should I choose 2.5X or 3.5X?
For general and routine dentistry, 2.5-4X is recommended. New users can start with 2.5X: a wide field of view that is easy to adapt to and covers most daily procedures; fast adapters can go straight to 3.5X. For fine work such as endodontics and aesthetic restorative, consider the Prismatic Pro at 4X-6X.
I have myopia or astigmatism — can I wear them?
Absolutely. One-on-one customization builds your prescription into the lenses, so there is no need to wear glasses under your loupes. Please provide a professional prescription issued within the last 6 months before ordering.
How do I measure my working distance accurately?
Sit in a healthy posture with your back straight and neck upright. With the patient reclined in the chair, measure the straight-line distance from the corner of your eye to the corner of the patient's mouth. This number is critical and must be accurate — after ordering, our customization consultant will guide you through the full measurement process.
Is a headlight mandatory?
Most dentists pair one, but it is not required. 2.5X/3.5X loupes take in plenty of light, so a well-lit operatory may be enough. A headlight is not about maximum brightness — adequate is enough, and you can always add an AcuBeam later if the field feels dim.
Custom-made to your parameters
The 25AV-ST is built to your interpupillary distance, working distance, and prescription. Send an inquiry — our consultant will confirm the details and quote one-on-one.
